Precision Machining

Advanced Machining utilizes best of class machining and measuring equipment to produce tooling, prototypes, and production parts. We serve leading OEM customers in a variety of demanding industries such as aerospace and defense, power generation, medical, research, automotive and others. We have experience with a wide range of quantities and material types, including high performance and exotic materials. Our staff has many years of experience and a high level of technical competency. Products and services include:

  • Prototype components – military, aerospace and commercial
  • Production manufacturing – automated machining with pallet changing
  • Dies – stamping, forming, compacting, extrusion, fine blanking
  • Hard die milling – up to 65 Rc
  • Mold cavities and cores – plastic die-cast, compression
  • EDM electrodes & special cutting tools
  • Inspection services & reverse engineering

Our equipment capabilities include:

Milling:

  • Automated 3 to 5-axis machining centers with spindle speeds up to 42,000
  • Laser tool measurement with robotic work loading.
  • Axis travels up to 40” x 26”
  • Capable of complex 3D geometry to close tolerances and superfine finishes.
  • Materials: all steel alloys, fully hardened steels, high nickel alloys, titanium, aluminum, ultra-hard ceramic composites, non-ferrous alloys, polymers.

EDM:

  • Automated, high accuracy, Swiss-built 5-axis Wire EDM systems with travels up to 20” x 14” x 16.5” thickness.
  • Automated 4-axis Sinker EDM systems capable of helical geometry and fine finishes
  • Materials: any conductive material including steels, carbide, nickel alloys, and refractory metals.

Turning:

  • Up to 10” diameter
  • Highly precise hard turning capability

Special Processes:

  • We have an extensive base of proven approved suppliers for materials, heat treatment, welding, plating, coatings and testing.

CAD/CAM

Advanced Machining utilizes Mastercam 3D solid modeling and CAM programming for CNC milling, turning and EDM processes. We commonly receive part drawings in the following formats: IGES, DXF, ParaSOLIDS, VDA, STEP, DWG and SAT, but can accommodate other formats as needed. We also utilize Spaceclaim Engineer to support 3D modeling.

Quality Assurance

Advanced Machining is AS9100C and ISO 9001:2008 certified. Documentation management is supported by ShopTech E2 enterprise software. Our gage blocks, surface plates and instruments are calibrated and traceable, per ISO9001:2008 requirements. Inspection systems include:

Zeiss Eclipse 550 ST CMM

  • Fully CNC controlled and networked
  • Zeiss ST 3D dynamic touch probe (w/fully automatic probe changing)
  • 0.00008 linear accuracy / 0.000022” volumetric accuracy
  • Temperature controlled environment
  • Calypso & Holos measurement software supports 2D and 3D measurement
